The code and guidance given here should not be used as the sole source of information to create production-ready code, also you should not eat tide-pods… raw, fry them first.

For this article I assume basic knowledge about the Wayland protocol, if you want resources those are the best ones at the time of writing [1] [2].

Creating and sharing shared memory with the wayland display server in Rust is not as straightforward as it may seem, so we’ll go step-by-step. In this article, we’ll implement Wayland’s wl_shm interface to provide a pixel buffer describing our window content.

First we need to create a memory-mapped file, for this we will use the tempdir crate (although it’s perfectly fine to implement it yourselves)

let folder = tempdir().unwrap();
let path = folder.path().join("mmap.ff");
let file = fs::OpenOptions::new()
    .read(true)
    .write(true)
    .create(true)
    .truncate(true)
    .open(&path)
    .unwrap();

We then want to set the filesize to “allocate” our memory :

file.set_len(size as u64).unwrap();

I then create a MmapMut struct with memmap2 to allow faster writing by converting our memory-mapped file into a memory-mapped buffer. This allows us not to use std::io functions (notably std::io::BufWriter) as they perform unnecessary write() syscalls and allocate memory even though our file is already in memory.

The same logic goes for reading via std::io::BufReader

Doing this implies adding unsafe code to our codebase because Rust cannot guarantee what ends up in our shared memory as everyone can write (given the right unix permissions) in it. As far as I know the wayland display server considers this shared memory as a read-only zone, so we shouldn’t suffer any undefined behaviour.

NOTE : I fill this shared memory with an image converted to the ARGB8888 format, one of the two format we know are required to work.

let raw_fd = file.as_raw_fd();
let mut mmap = unsafe { MmapMut::map_mut(&file).unwrap() };

// Filling the shared memory with our image
// NOTE : image is of type &image::DynamicImage
let pixels: &mut [u32] =
    unsafe { std::slice::from_raw_parts_mut(mmap.as_mut_ptr() as *mut u32, size) };
// RGBA -> ARGB8888 While following the host's endianness
for (i, chunk) in rgba.chunks_exact(4).enumerate() {
    let r = chunk[0] as u32;
    let g = chunk[1] as u32;
    let b = chunk[2] as u32;
    let a = chunk[3] as u32;
    pixels[i] = (a << 24) | (r << 16) | (g << 8) | b;
}

Everything is ready ; our shared memory was created and filled with an image in ARGB8888 format. We just need to share it with wayland… why do I hear boss music !?

The keen-eyed may have spotted a problem, how the hell do we send a reference to our shared memory ?? Well the reason we use memory-mapped file is that we can send it’s file descriptor, without this we would be sending whole argb8888 buffers across the wayland Unix socket like cavemans. We can’t just send the file descriptor as-is inside a message, we need to send it as 𝒶𝓃𝒸𝒾𝓁𝓁𝒶𝓇𝓎 𝒹𝒶𝓉𝒶.

QUESTION : Isn’t a file descriptor just an int !? Why can’t we send the the file descriptor like any other argument ??
True, but a file descriptor is relative to our process file descriptor table, we need to involve the kernel to “transfer” the file descriptor to another process.
For more details, see the “Ancillary messages” chapter

In the faraway lands of C this is done via the sendmsg and recvmsg functions, although in Rust well… At the time of writing (rust v1.9.3) SocketAncillary is a nightly feature, thus I can’t recommend it in good faith. Hence we are obligated to use C bindings, the nix crate provides us with safe bindings to select functions of the libc, including the nix::sys::socket::sendmsg function.

let iov = [IoSlice::new(b"")];
let cmsg = socket::ControlMessage::ScmRights(&[raw_fd]);
socket::sendmsg::<socket::UnixAddr>(
    wayland_socket.as_raw_fd(),
    &iov,
    &[cmsg],
    socket::MsgFlags::empty(),
    None,
)
.unwrap();

To recap, what we have done is creating a memory-mapped file (and using it as memory-mapped buffer for optimization) and sent the corresponding file descriptor via ancillary data via the Unix socket used for communication with the wayland display server.
